Audi CarPlay Android Auto MMI 2G High A4 A5 A6 A8 Q7 (2002 - 2011) Integration with fiber sound connection

Carplay MMi wirelessly connects your mobile phone to your car, and enables Apple CarPlay, Android Auto, Screen-mirroring, AirPlay, USB Playback. Use Google Maps, Waze, Spotify, Youtube Music and other apps on your car’s original screen!

Compatible Audi models with Audi Carplay MMi 2G High:


  • A4 (8K) 2008-2009
  • A5 (8T) 2007-2009


  • A6 (4F) 2004 – 2009
  • A8 (8E) 2002 – 2009
  • Q7 (4L) 2004 – 2009

Apple Carplay wireless works with all iPhones running iOS 10 and later.

Android Auto wireless works with most Samsung, Google and other Android phones running Android 10 and above.


Stock left:
26pin - A6 / A8 / Q7: 2
20pin - A4 / A5: 2

Item stock >1 will be delivered in 4-7 working days!
Item stock <1 will be delivered in 7-11 working days World Wide!

Freaqueantly ordered together


Audi CarPlay Android Auto Integracija MMI 2G High A4 A5 A6 A8 Q7 (2002 – 2011) Integration with fiber sound connection

MR12Volt is the only company that produces Audi Carplay Android Auto integration for the MMi 2g High system. It is the highest quality product and the only one on the market that uses a MOST connector (optical cable) for audio transmission, so that the sound quality remains unchanged. This is especially important for cars with premium sound systems like BOSE or Bang & Olufsen.

The Audi Carplay MMi uses the original MMi 2g High system display, so the look and feel of the car’s interior will be maintained.

Both Android and Apple phones connect to the device via Wi-Fi and Bluetooth, so there’s no need for a USB cable.

Audi Carplay MMi The device menu is controlled using the original system controls – the dial, buttons and switches on the steering wheel – to preserve the original Audi driving experience.

Audi Carplay is fully integrated with the original parking systems – the unit automatically switches to the rear view camera or parking sensor when reversing and disconnects when gear switches back to drive.

Audi Carplay allows you to connect front and rear cameras, even if the car did not previously have this function.

The Audi Carplay wiring harness connects to the original connectors, eliminating the need to cut and solder wires. The unit is fully ready to use and does not require any additional programming to the car.

Main Audi Carplay MMi benefits:

  • No need to change the original multimedia display.
  • The audio is connected via a MOST optical cable (not via AUX), so sound quality is maintained.
  • Interface via Wi-Fi and Bluetooth, or USB cable.
  • Original functions are retained – you can return to the original menu at any time.
  • The original display of vehicle cameras or parking sensors is retained.
  • Control by steering wheel, original wheel or phone.
  • Voice control using Siri or Google Assistant.
  • USB interface for music or video playback.
  • Sound system equaliser function.
  • Possibility to connect additional front and rear cameras.
  • Tidy installation – no need to cut or solder any wires, everything connects with the original connectors.
  • Publicly available software updates on the manufacturer’s website.
  • CE / ROHS / FCC / ISO9001 certification.

The unit comes with a 1-year technical warranty.

Warning: the system occupies the space of the CD changer, so the CD changer will not work after installation!

Important: You will not be able to listen to FM radio and use Apple Carplay or Android Auto at the same time, as the audio channel is automatically switched when the system is activated. You can listen to the radio online via the Tune-in app.

Wireless Android Auto works with Android 10 software system and above.

Wireless Apple Carplay works with iOS10 software system and above.

Notice: Huawei mobile phones with Android 10 (EMUI10) works only via USB cable!

Important: This product is only compatible with the Audi MMI 2G High navigation system. It does not work with MMI 2G Basic/Low (red and black information display).


Operating temperature: -20 – +80 degrees Celsius
DAC resolution: 18-bit
MP3 kbit: 8 – 384kbit
Voltage: 10 – 14.6 V DC
Operating current: 450 mA (700 mA for mobile phone charging)
S/N ratio: 95 dB
Total Harmonic Distortion: 0.1%
Frequency response: 20Hz – 20KHz



Videos of installation examples:

Audi A6 2004-2009 MMI 2G High

Audi A8 2002-2008 MMI 2G High

Audi Q7 2004-2009 MMI 2G High

Audi A6 2004-2009 P2000-2G26M0 working example video
